2.3MP HD Global Shutter USB Camera Module 1080P 90FPS 1/2.6" CMOS USB2.0 Plug And Play With 5-100mm Varifocal CS Mount Lens

$201.92

Includes all taxes

Ships From
Plug Type
Quantity
Meet your Seller
Delivery options
  • Ship Only

Description


Enhance the flexibility and efficiency of your industrial applications by choosing our customizable industrial cameras! Whether it's the housing design, cable length, lens specifications, or special features, this camera can provide you with tailored solutions.

2.3MP HD Global Shutter USB Camera Module 1080P 90FPS 1/2.6" SONY CMOS USB2.0 Plug And Play With 5-100mm Varifocal CS Mount Lens

1080P 90FPS Global Shutter Aptina AR0234 Sensor Overview

  1. Sensor Specifications: The Aptina AR0234 is a 1080P global shutter sensor (1/2.6”) designed for high-quality imaging.

  2. Shutter Type: Featuring a global shutter, this camera excels at capturing high-speed moving subjects with crisp, sharp images. It effectively eliminates rolling artifacts, providing a more accurate and complete picture compared to rolling shutter cameras.

  3. High Frame Rate: The camera supports high frame rates, delivering MJPEG video at 90fps in resolutions

  4. Plug & Play: This camera is UVC-compliant, allowing for easy connectivity. Simply plug it into a PC, laptop, Android device, or Raspberry Pi via USB—no additional drivers required.

  5. Lens Options: An optional fixed focus lens is available for enhanced versatility.

Global Shutter vs. Rolling Shutter:

Global Shutter Cameras: Perfect for capturing high-speed motion with clarity, these cameras prevent issues like partial exposure, skew, and wobble, which are common with rolling shutter cameras.They are particularly effective for short exposure times (e.g., <500µs).

Rolling Shutter Cameras: Better suited for longer exposure times (e.g., >500µs), making them more suitable for different imaging scenarios.


Applications: The combination of high image quality, elevated frame rates, and good sensitivity makes global shutter cameras ideal for various applications, including:

  • High-speed sports photography

  • Industrial inspection

  • Video applications

  • Industrial automation

  • Robotics

  • Scientific imaging

  • Augmented and virtual reality

  • Gesture and eye tracking

  • Depth and motion detection



Model No.

WGWK-QJ200

Sensor

AR0234(1/2.6” )Global Shutter

Max Resolution

1920(H) *1200(V)

Lens Size

1/2.6 inch169

Pixel Size

3.0um *3.0um

Image area

TBD


Compression Format

MJPEG / YUV2YUYV

Supported resolution and frame rate

1920*1200 @ 90fps MJPEG

1920*1200 @ 5fps YUV

1920*1080@ 90fps MJPEG

1920*1080 @ 5fps YUV

1280*960 @ 90fps MJPEG

1280*960 @ 5fps YUV

1280*720 @ 120fps MJPEG

1280*720 @ 15fps YUV

800*600 @ 120fps MJPEG

800*600 @ 20fps YUV

640*480 @ 120fps MJPEG
320*240 @ 120fps MJPEG

640*480 @ 30fps YUV
320*240 @ 90fps YUV

Camera Board Assembly Technology

SMT


Focus

fixed


Center clarity

600LW/PH (Center)

Signal-to-Noise Ratio

38dB


Dynamic Range

71.4dB


Sensitivity

1.4V/lux-sec@550nm

Minimum illumination

0.3lux


Shutter type

Global shutter

Interface Type

USB2.0


Automatic Exposure Control AEC

support


Automatic White Balance AEB

support


Automatic Gain Control AGC

support


Adjustable parameters

Brightness Contrast Color Saturation Hue Sharpness Gamma White Balance Backlight Contrast Exposure

Lens specifications

CS Mount Lens:4mm/6mm/8mm/12mm/16mm/2.8-12mm/3.6-10mm/5-50mm/5-100mm

Light board power supply interface

/

Power supply and interface

CON_5PIN1.25 Vertical Seat

Voltage

USB-5V

Current

80mA- 280mA

size

38mm(L) × 38mm(W) x24mm(H)

Storage temperature

-40°C to 85°C

Operating temperature

0°C to 70°C

USB cable

1M(2M/3M/5M optional)

System Support

Win XP/Vista/Win7/Win8 / Linux with UVCabove linux-2.6.26

MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC


Step 1: Install Computer USB Camera Software - amcap

Contact customer service to obtain the software installation package.


Step 2: Connect the computer using a USB cable.


Step 3: Adjust the focal length to achieve a clear image.About us:
