3 Axis 1212 1200*1200mm 3d Woodworking Cnc Router Engraving Carving Machine

$1,595.58

Includes all taxes

Color
Quantity
Meet your Seller
Delivery options
  • Ship Only

Description

3 Axis 1212 1200*1200mm 3d Woodworking Cnc Router Engraving Carving Machine



Products Parameter


Description

CNC Router Specifications

Model

Rakoncnc RC Series

X,Y axis

Working size

600x900mm / 1200x1200mm

Z axis working size

200mm standard

( customization optional )

Control system

Nc studio; A11 DSP

Spindle power

1.5kw water cooling ( 0 - 24000rpm )

Motor

Stepper motor

Rail guide

Square

Transmit

X Y Z ball screw

Working speed

0-15000mm/min

Command code

HPGL, G code

Working precision

0.05mm

Power supply

AC 220/380V±10%,  50Hz/60Hz

Compatible software

Type3/Artcam/UG/Pro-E/Mastercam/Ucancam V9 etc




Optional parts

1. Change control system

2. Vacuum worktable

3. Rotary Clamp

4. Spindle power

5. Water tank(for metal
and stone )

6. Change to Cloose loop stepper motor or Japan Servo Motor


Why choose us


1 We are a real factory offering products.

2 Free technical advice by QUALIFIED MECHANICAL ENGINEERS.

3 Company in business for many years.

4 Over 50 countries customers served!

5 Buy direct saving your money!

6 All machine with CE, ISO, BV certificate.

7 Machine and spindle warranty 1 year.

8 Our engineer can go to your country to provide technical guidance



Product Features Of CNC ROUTER


1.Adopt imported square guide rail,double row slide block and the imported ball screw makes the machine working steadily,high precision and long life time.

2.With advanced DSP system,operated with the USB handle,convenient operation, humanization design.

3.High power spindle, brushless, water cooling, working vigbrously with low noise , guarantees long time mass processing.

4.Adopt high speed stepper motor and drivers and to motors for Y axis,max speed can reach to 35m/min,auto aligning system.

5.Compatible with type3/artcam/castmate/proe/coreldraw/wentai and other cad/cam software.



Products Description

Ball screw on all axis

There are three ball screws, one for each axis.Each ball screw is driven by a stepper motor and moves the router spindle in the X,Y and Z directions.


Taiwan square guide rails

The square rail is with higher stability and rigidity, which makes the gantry moving and spindle moving at high speed with high precision.


Machine body design

Ruggedly constructed machine structure. Material is Stress relieved and  annealed for deformation free, thus always keep machine accurate. Machine base is produced by CNC machine, and machine base's five sides are produced at one same procession to make sure the machine body geometry tolerance is standard.

Water cooling spindle

1.5kw high frequency spindle,more powerful and less noise.With water cooling ,it will have long working life.



Sample Display


  • Application material

    Wide range of application:

    Such as seal, packing, scutcheon and pane, decorating, art and craft, architecture model, souvenir, badge, electric circuitry and carpentry field.

    Suitable for Materials:

    Engrave and cut on Acrylic sheet, ABS double color sheet, PVC foam sheet,wooden sheet, PCB Aluminum brass, steel etc.
