The DSE 8610 MKII represents the latest in sophisticated load sharing and synchronous control technology.Designed to handle the most complex grid-based generator applications, the DSE 8610 MKI control module offers a wide range of features and benefits that are unmatched in the generator control industry.
The DSE 8610 series modules can be used at different levels of functionality on a common platform, giving generator set OEMs a great deal of flexibility in selecting modules for certain application areas
DSE 8610 series modules allow users to start or stop the genset and switch the load from the mains side to the genset side manually (via navigation buttons on the panel) or automatically DSE8610 series modules come with their own synchronization and load sharing functions, providing the necessary protection functions for the system, and the user can also view the operating parameters of the system through the LCD screen
DSE 8610 series module can monitor the engine, display the operating status and fault condition of the unit, when there is an alarm, the engine will automatically shut down, buzzer or sound and light alarm and LCD display alarm content
Overall dimensions: 245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")
Panel cutouts: 220 mm x 160 mm (8.7 "x 6.3")
Maximum panel thickness 8.0 mm (0.3")
Weight: 0.88 kg
peculiarity
1.DSE8610 self-starting load sharing parallel module, which can be used to control EFI or non-EFI and gas engines, providing advanced engine monitoring and protection functions.It realizes intelligent load distribution control, which has the characteristics of advanced functions, convenient debugging and simple use
2.With manual/automatic function
3.It has the functions of controller, load distributor and synchronizer (3 functions in one) intelligent, humanized and parallel, simple to operate, similar to "point-and-shoot camera."
4.Support EFI or non-EFI or gas engine
5.Display engine parameters, generator parameters, unit power and busbar parameters without any instrument, support multiple Chinese, and display content can be edited (including Chinese)
6.It has the function of peak shaving adjustment
7.With engine and generator monitoring and protection functions, engine speed, engine oil pressure, engine water temperature, battery voltage, generator voltage, generator current, engine frequency·RS232, RS485, program setting port, network port and U disk port can be used at the same time through DSE8005 monitoring software (free), network monitoring (centralized monitoring) can be realized
8.The module contains a powerful ARM microprocessor, which can realize more complex functions!Voltage, current display and power monitoring of true RMS;
9.Monitor multiple parameters of the engine;
10.Input customizable alarms or other functions, etc.:
11.Support EFI engine;
12. When synchronizing and load sharing, the module is directly connected to the governor and the voltage regulator;
