Electronic Handwheel Pulse Generator CNC MPG Pendant 4 Axis 6 Axis 5V Jog Controller with Emergency Stop

$238.28

Includes all taxes

Quantity
Meet your Seller
Delivery options
  • Ship Only

Description


1.NOTE

Default configuration

Power Supply:Universal 5V

Number of Axes:2-axis / 4-axis / 6-axis

With E-stop / Without E-stop

Back with strong magnet

Cable length: 3–4 m (standard stretch)

Max. Sink Current:20mA

Response Frequency:10KHz

Due to space limitations, some specifications may not be listed. For specific customization requirements, please contact us.


2. Parameters

Model

T1

T2

L

Power(DC)

12 ± 0.5V

5 ± 0.5V

5 ± 0.25V

I<sub>cc</sub>

≤60mA

≤80mA

≤150mA

output signal

H

≥85%Vcc

≥2.5V

L

≤0.5V

Max. Sink Current

20mA

Signal Rise/Fall Time

≤1μs

≤200ns

Response Frequency

10KHz

Starting Torque

2×10⁻³ N·m(+25℃)

Moment of Inertia

1×10⁻⁵ kg·m²

Max. Load

Radial: 20 N, Axial: 10 N

Allowable Mechanical Speed

1000r/min

Operating Temp.

-10℃~+70℃

Storage Temp.

-30℃~+85℃

Humidity

30~85%(No condensation)

Anti-vibration

49m/s²,10~200Hz,2h per X, Y, and Z direction

Impact-resistant

980m/s²,6ms,3 times per X, Y, and Z direction

Weight

Approx. 0.5 kg (excluding cable)


3. Features

Universal CNC Compatibility
Supports FANUC, Siemens, Mitsubishi, KND, SYNTEC, and other popular CNC systems.

Precision-Machined Metal Dial
High-grade encoder with laser-etched scale for accuracy and durability.

Fire-Resistant Metal Housing
Strong, heat-resistant shell ensures long service life and improved safety.

Stable Signal Output
Low angular error with accurate signal positioning and fast response time.

Anti-Slip Base Design
Firm contact with the surface prevents slippage during use.


4. Applications

Ideal for CNC lathes, machining centers, engraving machines, and drilling equipment.
Widely compatible with both domestic and international CNC control systems.


5. FAQs

Q1: Is this compatible with FANUC and Siemens systems?
A1: Yes, this handheld pulse generator is fully compatible with FANUC, Siemens, Mitsubishi, SYNTEC, KND, and more.

Q2: What’s the maximum signal response speed?
A2: It supports up to 10KHz frequency with rise/fall times as low as 200ns, ensuring fast and accurate performance.

Q3: Is this product suitable for industrial environments?
A3: Absolutely. It features vibration and shock resistance, a fire-resistant housing, and stable operation in tough conditions.
