Features:
1. Ultra small size: only 21x18mm, designed specifically for space constrained scenarios.
2. Rich interface: up to 11 10 supports multiple interfaces, including analog, digital IIC、UART、SPI。
3. Powerful CPU: A powerful core with powerful performance, suitable for various complex applications.
4. SMT design: Single sided components, surface mount design, easily integrated into other boards for mass production.
5. Dual RISC-V cores: High performance and low power consumption work together to achieve seamless interoperability in smart homes.
Product Introduction:
ESP32-C6 is a cost-effective MCU based on Espressif ESP32-C6. This compact MCU performs well in smart home applications that comply with Matter standards, supporting various wireless connections (2.4GHz Wi Fi 6, BLE 5, Zigbee, and Thread). It adopts a thumb sized and single-sided installation design, which is very suitable for projects with limited space. ESP32C6 is encrypted on the chip and easily integrated with major IoT cloud platforms, ensuring the required level of security, simplified development experience, and fast market access.
Product Parameters:
Model: ESP32-C6/ESP32-C3
Processor: ESP32-C6 32-bit RISC-V processor, high-performance with a running frequency of up to 160 MHz
Wireless: Complete 2.4GHz Wi Fi 6 subsystem
BLE: Bluetooth 5, Bluetooth Mesh Zigbee、Thread、IEEE 802.15.4
On chip memory: 512KB SRAM and 4MB Flash
Interface: 1 x UART、1x LP_UART、1x IIC、1x LP_IIC、1x SPI、11x GPIO(PWM)、7x ADC、1xSDIO、1x Reset button, 1x start button
Input voltage (Type-C): 5V Input voltage (BAT): 4.2V
Working voltage (preparatory work):
-USB: 5V@9mA
-BAT: 3.8V@9mA
Rechargeable battery current: 100mA
Power consumption model: (power supply: 3.8V)
Modems sleep mode:~30mA
Light sleep mode:~2.5mA
Deep sleep mode:~15 μ A
Working temperature: -40 ° C~85 ° C
Size: 21mm x 18mm
Product List 1:
1X development board
2X needle arrangement
Product List 2:
1X development board
2X needle arrangement
1X antenna
