PDA Android handheld terminal Honeywell barcode scanner 1d laser 2d QR portable data collector terminal device with WIFI 4G NFC

$651.11

Includes all taxes

Ships From
Quantity
Meet your Seller
Delivery options
  • Ship Only

Description

Noted:
1. This PDA link isnot include the Charge Cradle, if you need, please check this link:

2. NFC function can be choosed, please contact us.



Android 13 Barcode Scanner with Numeric Pad Mobile Computer with 2D Scanner 4.5-inch Handheld Rugged PDA Support Wireless Wi-Fi 4G LTE

Product certification:

  • OS: Android 13

  • CPU: ARM Cortex-A53 64bit Octa-core

  • RAM+ROM:4+64GB

  • IP rating: IP66

  • Safety specification: IEC2 /FDA Ⅱgrade,conform IEC60825shy/EN60825-1 standard

  • Working life: No less than 5 year

  • Camera: 8MP autofocus camera with flash

  • Bluetooth: Support 2.0+EDR/3.0+HS/4.0+HS Transmission distance is 5-10m

  • Battery capacity:Rechargeable Li-polymer Battery 3.7V 4200mAhOptional. RTC battery keeps time not lost.

  • Drop specification: 6 sides can bear impact from 1.5m drop to cement floor about 30 times in the range of operating temperature

  • Scanner engine(Optional)

  • 1DLaser scanner (optional):Minde SE966 / Honeywell N4313, Support Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codaber, Interleaved 2 of 5, China post 25, ISBN/ISSN, Code93, UCC/EAN-128, GS1 Databar, HIBC, etc.

  • 2DCMOS scanner (optional):2D 6602/ Honweyll N5703, Support PDF417, MicroPDF417, GS1 Composite, Aztec, Code, Data Matrix, QR Code, Micro QR Code, MaxiCode, Hanxin Code, etc.


Data Communication:

  • WI-FI: Support IEEE802.11a/b/g/n, it need effective wireless LAN signal cover

  • 4G: FDD-LTE (B1/B2/B3/B5/B7/B8/B20) TDD-LTE (B40)

  • 3G: WCDMA (850/900/1900/2100MHz)

  • 2G: GSM(850/900/1800/1900MHz)

  • BT: Support 2.0+EDR/3.0+HS/4.0+HS (Transmission distance is 5-10)

1D/2D Honeywell scanner

Many brands of scan heads are available.

Honeywell scan heads are recommended for faster scanning speed and more stable performance.

NFC Function (Optional, contact us to add money)

Upport: 13. 56MHz; IS01443A/B, IS01 5693;Reading distance: 2cm-5cm

Physical Keypad
  • Built inF1,F2,F3,Easier to develop your own APP
  • Built inThree scan buttons,scan comfortably no matter how to hold.

Compatible with free software ocra scan


The Application of the App:
1.Scan product entry information and export form,includes Excel,CSV,HTML,JSON,XMLfile
2.How to use the free APP:
1). Open the app to scan, you can use the camera to scan or directly use the scan head scanning.
2). Product information can be edited after scanning, name, quantity, date and description, etc.
3). Click Export to export data
Where can use the device:
Warehouse management, Logistics express, Food Security, Supermarket, Library, Manufacturer, Airport and so on.
Packed with:

1* mobile android pos terminal,
1* 4200mAh battery,
1* Type-C cable & Adaptor.

You can use the SDK we provide to customize your software


Frequent Questions and Answers
Q1: Can the device be used in my country via 4G LTE network?
A: Yes, it supports global 4G LTE network.
Q2: Does this device support dual band with 5ghz and 2.4ghz wifi?
A: Yes.
Q3: What languages do the device support?
A: Our device support global languages, rest assured to use it in your country.
Q4 Does this device work with scanning usps, ups and fedex barcodes?
A: Yes, our terminal support to scan this kinds of barcodes.
Q5: What is the range on the scanner for scanning?
A: It depends on the size of the codes.
Q6: Can this scan a barcode presented on a smartphone screen?
A: Yes, the model with 2D scanner can scan the codes on the Electronic screen
Q7: Does this device have phone capabilty?
A: Yes, you can use it as a smartphone with barcode scanner.
Q8: Can I develop App based on SDK by Java language?
A: Yes, you can use the Java language develop your App in Android studio.
Q9: How do I use the F1, f2 and F3 buttons?
A: You can customize the F1, F2 and F3 with our SDK for this handheld terminal.



Physical Parameter

Dimensions

166mm(L)X77.5mm(W)X22mm(D)

Weight

<500g

Display Screen

Color 4.0 inch QVGA imitative glass durable touch screen

TFT-LCD, 650000 colors, 480*800 (QVGA size)

The brightness of LED Backlight is adjustable

Expand Port

SIM card, Micro SD (TF) Card

Communication Interface

USB2.0 Device,

Input Mode

Standard Stylus, Handwriting, touching input or keyboard input

Battery Capacity

Rechargeable Li-polymer Battery 3.7V 4000mAh Optional

Frequency

8 1W speaker

Buttons

21pcs soft silicon key

Data Communication

WI-FI

Support IEEE802.11b/g/n protocol, it needs effective wireless LAN signal cover

FDD-LTE  4G

Uplink:  1920MHZ-1980MHZ;  Downlink:  2110MHZ-2170MHZ

Uplink:  1710MHZ-1785MHZ;  Downlink:  1805MHZ-1880MHZ

Uplink:  2496MHZ-2690MHZ;  Downlink:  2496MHZ-2690MHZ

WCDMA  3G

Uplink:1850MHZ-1910MHZ;  Downlink: 1930MHZ-1990MHZ

Uplink:880MHZ-915MHZ;  Downlink: 925MHZ-960MHZ

GSM   2G

850MHZ,  Uplink:824MHZ-849MHZ;  Downlink: 869MHZ-894MHZ

900MHZ,  Uplink:880MHZ-915MHZ;  Downlink: 925MHZ-960MHZ

1800MHZ,Uplink:1710MHZ-1785MHZ;  Downlink: 1805MHZ-1880MHZ

1900MHZ ,Uplink:1850MHZ-1910MHZ;  Downlink: 1930MHZ-1990MHZ

Bluetooth

Support Bluetooth 2.0+EDR/3.0+HS/4.1+HS, transmission distance is 5-10m

Operating Environment

Operating Temperature

—20C to 50C

Storage Temperature

—25C to 70C

Environment Humidity

5%RH--95%RH(no condensation)

Drop Specifications

6 sides can bear impact from 1.5m drop to cement floor in the range of operating temperature

Roll Specifications

1000 times/0.5m, roll on 6 sides contact area

Sealed Environment

IP65

Development Environment

Operating System

Android

SDK

exclusive use software development kit

Supported Language

JAVA

Development Tool

Eclipse

1D Laser Scanner

One dimensional laser scanner

Minde966 or Honeywell N4313

Resolution

4Mil minimum width

Ambient Light

10000ft.candles(107640 lux)

Scanning Speed

104(±)12/sec (both way)

Scanning Angle

47o±35o(Standard) / 35o±3o(narrow angle)

Support Bar Code Type

UPC/EAN, Code128, Code39, Code93,Code11, Interleaved 2 of 5,
Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS

2D CMOS (Optional)

CMOS Scanner

2D 6602 or Honeywell 5703

The Sensor Resolution

752(level)×480(vertical)pels(gray level)

Ambient Light

All dark 9000ft.candles/96900 lux

Focus element (VLD)

655nm ± 10nm

Support bar code type

PDF417,MicroPDF417,Composite, RSS,TLC-39, Datamatrix,
QR code, Micro QR code, Aztec, MaxiCode;
Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal,
JapanPostal Dutch Postal (KIX)3

NFC(Optional)

NFC

13.56MHz

If you need the NFC

Please choose the NFC optional

Camera

Hd 8 million pixels, with LED, automatic focusing

GPS

Support A-GPS

Android 13

CPU

ARM Cortex-A53 64bit Octa-Core 1.3G

RAM

4G

Flash ROM

8G NAND Flash Storage

or 64G NAND Flash Storage
