Wood Chip Biomass Straw Mini Pellet Flat Die Small Scale Wood Pellet Mill Feed Processing Machine

$19,379.61

Includes all taxes

Quantity
Meet your Seller
Delivery options
  • Ship Only

Description

Product Description

Flat die wood pellet machine is the use of crops corn stalk, straw, straw, peanut shell, corn cob, cotton stalk, soybean stalk,rice husk, weeds, branches, leaves, sawdust, bark and other solid waste as raw materials, after crushing, pressure, densification,molding, become a small stick solid rest pellet fuel. Pellet fuel is made of wood chips and straw scales by pressing roller and ring die at room temperature. The density of raw materials is generally about 110-130kg/m3, and the particle density after molding is greater than 1100kg/m3. It is very convenient for transportation and storage, and its combustion performance is greatly improved.

Specification

Flat die sawdust pellet machine is mainly used for crude fiber compression molding, such as corn stalk scale, wood chips of various crops such as rice husk, cotton stalk, weed stalks scales, living garbage, factory waste, bonding rate is low, it is difficult to molding material granulating, rural farming farmer and farm feed particles, also can be applied to bio-bacterial
manure, organic fertilizer and compound fertilizer granulation in low temperature. The motor drives the machine spindle to rotate after changing speed through the reducer, the spindle is connected with the press roller shaft, the mold is static, the press roller and the mold material friction rotates, the material is pressed out through the mold, the cutter cuts off the pressed
material and then falls into the dumping plate, thrown to the machine hopper, the pelleting is completed.
Technical Data
We also offer different diameters of pellet machine grinding mould. (The length of pellets can be adjusted freely)
Model
Capacity
Power
Reducer Model
Dimensions
Weight
BD-250
100-200kg/h
15kw
KAF87
1120*440*1060mm
400kg
BD-300
200-300kg/h
22kw
KAF97
1280*560*1220mm
700kg
BD-350
300-400kg/h
30kw
KAF107
1300*600*1250mm
800kg
BD-400
400-600kg/h
37kw
KAF107
1390*650*1290mm
1000kg
BD-450
600-800kg/h
45kw
KAF127
1620*700*1600mm
1500kg
BD-500
800-1000kg/h
55kw
KAF127
1620*700*1600mm
1600kg
Details Images

1.Flat die wood pellet machine material after compression molding, without adding any raw materials, a machine multi-purpose granulation, rod, pressure block as long as the exchange of the mold can be done.
2.Good stability, high output, low power consumption, low price, simple operation, easy to move. Diesel engines can be substituted for non-electric utilities.
3.The machine shell is made of nodular cast iron, and the spindle press roller shaft is modulated and machined. It has high strength, good stability and is not easy to deform, and improves the accuracy and prolonging the bearing life. Pelleting chamber with observation door can be inspected and repaired at any time.
4.The motor adopts energy-saving and environmental protection motor, star triangle decompression start control cabinet, small start current, less power consumption.
5.The increase of the outer diameter of the press roller makes the temperature generated by extrusion not easy to be transmitted to the bearing room, so as to ensure that the bearing works at low temperature; Bearing is also increased to enhance the compression capacity; The press roller is fully sealed to prevent the phenomenon of dust, to ensure that oil does not overflow. Prolong the service life of the roller bearing, improve the work efficiency and reduce the cost.
6.The mould and roller are made of high quality alloy steel and advanced carbonizing heat treatment process to improve the service life.
