Model | L02M32T | L02M32R | L02M24T | L02M24R | |
Programming language | Ladder diagram (LD) / instruction list / Sequential function chart (SFC) | ||||
Program capacity | 32k steps | ||||
Weight(kg) | 0.35 | ||||
Storage capacity | Date (D) | [D0~D127] 128points General / [D128~D7999] 7872points Retentive / [D8000~D8511]512points Special | |||
Expansion(R) | [R0~R22999] 23000points. Support power-down retention / [R23000~R23999].1000points Internal use | ||||
Expansion model | Max limit of 31 units: max 12 analog input/output respectively | ||||
Max l/O | FX3U mode: 512 points; FX3G mode: 256 points (the sum of input and output points) | ||||
CPU Digital I/O | 16DI / 16DO | 12DI/ 12DO | |||
CPU analog I/O | / | 4AI/4AO | |||
AI Type | / | 2*0-10V, 2*0-20mA(4-20mA) | |||
AO Type | / | 2*0-10V, 2*0-20mA(4-20mA) | |||
Timer T | [TO~T199] 200points 100ms General / [ [T250~T255] 6points 100ms Retentive | ||||
[T246~T249] 4points 1ms cumulative Retentive / [T256~T319] 64points 1ms General | |||||
[T200~T245] 46points 10ms General | |||||
※The 10ms timer is affected by the scan period. | |||||
lf the scan period is 12ms,the timer becomes 12ms and executes once. | |||||
16-bit counter C | [CO~C15] 16points General | ||||
32-bit counter C | [C200~C219] 20points General | [C220~C234] 15points Retentive | |||
[C235~C245 Single phase single counting][C246~C250 single phase double counting] | |||||
[C251~C255 Two-phase double counting] | |||||
High-speed pulse | 4-channels 150KHz+4-channels 50KHz | ||||
High-speed counter | Single phase 6 channels 60KHz, | ||||
or AB(Z) phase 2 channels 60KHz+AB phase 1 channel 10KHz | |||||
Do type | L02M32T/L02M24T: Transistor output, load maximum 500mA, low level NPN, COM connected to negative | ||||
L02M32R/L02M24R: Relay output, load maximum 2A, dry contact, COM can be connected to positive or negative | |||||
Default COM | Type-C, RS-232, RS-485*2, Ethernet, CAN | ||||
Protocol | Programming port Modbus RTU, Modbus TCP, Modbus UDP, | ||||
freeport protocol, CAN, Ethernet/IP, BD board | |||||
Data backup function No | Program | Flash ROM | |||
battery storage | |||||
Retentive area | MRAM has no write limit | ||||
Calendar(RTC) | Commercially available batteries CR1620(optional) | ||||
Self-diagnosis | CPU abnormalities, internal memory problems, etc | ||||
Rated input voltage | 24VDC(土10%) | ||||
Software | Compatible with GX WORKS 2 | ||||
Detailed info. refer toCoolmay L02 Series PLC Progarmming ManualL02 Series PLC Controller User Manual | |||||
