M5Stack Official ATOM Voice or Base ASR ESP32 Programmable Smart Speaker Development Board Kit For Home Assistant Voice Control

$21.60

Includes all taxes

Meet your Seller
Delivery options
  • Ship Only

Description










Please note order optional


Option1 ATOM Echo

Option2 Atomic Echo Base

Option3 ASR Unit

Option4Atom EchoS3R





M5Stack ATOM Echo Programmable Smart Speaker ESP32 Development Board


 Product Features
  • Light and small

  • Support STT services

  • Based on ESP32, Support A2DP

  • 2.4G Wi-Fi IEEE 802.11b/g/n

  • Built-in microphone and speaker

  • RGB LED status display indication

  • GROVE extension interface

  • Record and playback

  • Programmable key

  • Programming platform: Arduino, ESP-IDF/ADF

Applications
  • BT Speaker

  • Voice control

  • IoT


 Package Includes

1x ATOM ECHO

 Specification

Resources Parameter

SoC: ESP32-PICO-D4,240MHz,Dual Core,Wi-Fi

Flash: 4MB

Interface: 1x IR-TX,1x Function Button,1x Reset Button

PinOut: G21/G25/5V/GND, 3V3/G22/G19/G23/G33

RGB LED: SK6812

Speaker: 0.8W/NS4168 I2S

Microphone: SPM1423 PDM

Net weight: 5g

Gross weight: 10g

Product Size: 24*24*17mm

Package Size: 85*65*17mm

Case Material: Plastic (PC)

 Product details
Schematic

 Real Photos


 Product Description
ATOM ECHO is a Programmable Smart Speaker based on the M5ATOM design. Its form factor is very small, its dimensions are only 24 * 24 * 17 mm. Music can be played using the BT capabilities of the ESP32 from a mobile phone or tablet. The device could be programmed to access AWS, Baidu and other cloud platforms, using the built-in microphone and speaker for voice interaction, so that ATOM ECHO has certain AI capabilities, realizing voice control, story telling, Internet of things and other functions. The speaker is embedded with an RGB LED (SK6812), which can visually display the connection status. In addition to being used as a BT speaker, it still has the control ability of Atom series.Screw hole on the back is convenient for users to fix.



 Kindly Remind


1, The Factory Test firmware is BT speaker, which uses A2DP protocol to transmit audio data(call reception is not supported). After power on, the red LED will be displayed. When the connection with BT device is established, the LED will turn green. At this time, the sound can be output through atom echo. The LED turns red when disconnected. The firmware is compiled on the esp-idf platform. If senior users need to develop other functions by themselves, they can build the environment according to the official documents of Espressif. See the following links for the source code of factory firmware and bin file, where the BIN file burning address is 0x0000.


2, Echo already supports HomeAssistant! The latest shipped devices with the sticker ESPHome FW Pre-installed for HomeAssistant have pre-burned ESPHome firmware, users can refer to the following link .Detailed tutorial reference Tutorials for setting up the M5Stack Atom Echo as a voice assistant for Home Assistant.


For those who are not using Home Assistant, you can flash the device with EasyLoader firmware, to resume the device to Factory Test status.


3, G19 / G22 / G23 / G33 has been defined, please do not reuse the above pins, otherwise ATOM ECHO will be damaged.

Note: please avoid such conditions with M5Stack Atom Echo.

DC output from I2S channel

Playing white noise for a long time

Playing full square-wave audio


 EasyLoader


Tutorials for setting up the M5Stack Atom Echo as a voice assistant for Home Assistant















 Product Description
The Atomic Echo Base is a voice recognition base designed specifically for the M5 Atom series. It uses an integrated solution with the ES8311 mono audio decoder, MEMS microphone, and NS4150B power amplifier. The ES8311 offers 24-bit audio resolution and a sample rate of 16KHz to 64KHz, supporting I2S communication and high-fidelity audio processing. The MEMS microphone with high signal-to-noise ratio (SNR) is suitable for automatic speech recognition, while the built-in speaker ensures efficient audio output. The device supports full-duplex communication, enabling simultaneous voice transmission and reception, enhancing interactive features such as speech recognition, wake-up, and audio playback. It is ideal for applications in smart homes and education.




 PinMap



M5Stack Atomic Echo Base

 Product Features

  • Compatible with the M5 Atom series

  • Voice recognition

  • Mono audio codec

  • MEMS microphone

  • Class-D amplifier

  • Speaker

  • Development platform

  • UIFlow 1.0

  • UIFlow 2.0

  • Arduino IDE


Applications
  • AI voice recognition interactive systems

  • Smart home control


 Package Includes

1x Atomic Echo Base

 Specification

Specification Parameter

Audio Codec: ES8311: 24-bit resolution, I2S protocol

MEMS Microphone: MSM381A3729H9BPC, SNR ≥ 65 dB

Power Amplifier: NS4150B: Class-D power amplifier

Speaker: 2014-type cavity speaker: 1W@8Ω

Standby Current: DC3.3V/3.36mA

Operating Current: DC3.3V/14.84mA

Operating Temperature: 0-40°C

Product Size: 24.0 * 24.0 * 14.14mm; Packaging Size: 85.0 * 65.5 * 15.0mm

Packaging Weight: 12.5g; Product Weight: 6.3g


Please note:

MIC Sampling Rate

The Atomic Echo Base microphone supports a sampling rate range of 16KHz-64KHz.

 Product Comparison
 Product details
Schematics
Module Size
M5Stack Unit ASR CI-03T AI Intelligent Offline Voice Module

 Product Features

  • CI-03T AI intelligent offline voice module

  • Noise reduction processing

  • 42 pre-installed commands

  • Supports up to 300 command words

  • UART serial communication

  • Supports custom wake-up word

  • Microphone and speaker

  • Development platforms:

  • UIFlow 1.0

  • UIFlow 2.0

  • Arduino IDE


Applications
  • AI Assistant

  • Smart Home

  • Security Monitoring

  • Automotive Systems

  • Robotics and Smart Hardware

  • Healthcare


 Package Includes

1 x Unit ASR
1 x HY2.0-4P Grove cable (20cm)

 Specification

Specification Parameter

AI Module: CI-03T AI Intelligent Offline Voice Module

Command Words: Supports up to 300 command words, Factory default 42 built-in commands

Wake-up Method: UART serial communication or voice keyword wake-up

Microphone: Analog microphone

Speaker: 8Ω@0.8W speaker (used for output device wake-up feedback)

Communication: UART serial communication, default baud rate: 115200@8N1

Noise Reduction: AEC (Acoustic Echo Cancellation)

Power Consumption: Standby Current: DC5V / 47.73mA; Operating Current: DC5V / 250.12mA

Operating Temperature: 0-40°C

Product Size: 48.0 x 24.0 x 16.0mm; Product Weight: 10.5g

Packaging Size: 136.0 × 92.0 × 13.0mm; Packaging Weight: 15.8g


 Product details
Schematics
Module Size



 PinMap



HY2.0-4P

Black

Red

Yellow

White

Port.C

GND

5V

TX

RX



 Product Description
Unit ASR is an AI offline voice recognition unit, built with the CI-03T AI intelligent offline voice module. The unit offers powerful capabilities such as speech recognition, voiceprint recognition, voice enhancement, and voice detection. It supports AEC (Acoustic Echo Cancellation), effectively removing echoes and noise interference, thereby enhancing voice recognition accuracy. It also supports mid-conversation voice interruption, allowing flexible interruption during voice recognition and quick response to new commands. The product comes pre-configured with 42 English wake-up words and feedback command words. It uses UART serial communication for data transmission and supports awakening the device via UART or voice keywords. The unit also supports user-customizable modification of multi-language wake-up recognition words by regenerating the firmware and can recognize up to 300 command words. Equipped with a microphone for clear audio capture and a built-in speaker for high-quality audio feedback, this product is widely used in AI assistants, smart homes, security monitoring, automotive systems, robotics, smart hardware, and healthcare. It is an ideal choice for implementing intelligent voice interaction.
