Stainless Steel 304 Spiral IQF Tunnel Freezer Corrosion Resistance Food Grade Quick Freezing Tunnel Machine

$107,914.94

Includes all taxes

Plug Type
Quantity
Meet your Seller
Delivery options
  • Ship Only

Description

PLEASE NOTE:

1.This product is custom-made, and the price shown is not the final price.

2.We can customize the color, configuration, model, appearance, logo, engine type, and powertrain.

3.We offer a variety of delivery methods, including DDP, DAP, EXW, FCA, FAS, FOB, CFR, CIF, CPT, CIP, DAT.Freight needs to be calculated based on the delivery mode.

4.The most important thing is that you need to communicate with our customer service to confirm the product parameters.Specific pricing varies depending on the country and custom requirements, please contact customer service.

5.Orders not confirmed by customer service will not be shipped!

email address :
3360212409@qq.com
whatsapp/Mobile : +86 13838215923

Custom Length Quick Freezing Tunnel Machine for Specific Factory Layout Space Saving
Products Description



Quick Freezing Tunnel – Advanced Frozen Food Processing Solution
The Quick Freezing Tunnel is an industrial-grade freezing system designed for rapid and efficient freezing of food products, ensuring optimal preservation of freshness, texture, and nutritional value. Ideal for meat, seafood, vegetables, fruits, and ready-to-eat meals, our freezing tunnel enhances production efficiency while maintaining the highest food safety standards.

Key Features

Ultra-Fast Freezing – Achieves rapid freezing at temperatures as low as -35°C to -45°C, minimizing ice crystal formation and preserving product quality. High Capacity & Efficiency – Continuous conveyor belt system allows for large-scale production with minimal manual handling. Uniform Freezing – Advanced airflow technology ensures even temperature distribution for consistent freezing results. Customizable Design – Available in various sizes and configurations to fit different production needs. Energy-Saving Technology – Optimized refrigeration system reduces power consumption while maintaining peak performance. Hygienic & Easy to Clean – Made from stainless steel (SS304/SS316) with smooth surfaces to meet food-grade sanitation requirements. Automated Control System – User-friendly PLC & touchscreen interface for precise temperature and speed adjustments.
Technical Specifications

Parameter
Details
Freezing Temperature
-35°C to -45°C(or as per requirement)
Freezing Time
30-200 mins (adjustable)
Conveyor Width
500mm – 1500mm (customizable)
Power Supply
220V/380V/460V-----50Hz/60Hz (or as per requirement)
Refrigerant
Eco-friendly (R404A, R507A, NH3, CO2 options)
Material
Stainless Steel (SS304/SS316)
Model
Nomonal Freezin Capacity
Inlet Feed temperature
Out-feeding temperature
Solidification point
freezing time
Outline
dimension
Cooling capactiy
Motor power
Refrigerant
SDLX-150
150kg/h
+15℃
-18℃
-35℃
15-60min
5200*2190*2240
19kw
23kw
R507A
SDLX-250
200kg/h
+15℃
-18℃
-35℃
15-60min
5200*2190*2240
27kw
28kw
R507A
SDLX-300
300kg/h
+15℃
-18℃
-35℃
15-60min
5600*2240*2350
32kw
30kw
R507A
SDLX-400
400kg/h
+15℃
-18℃
-35℃
15-60min
6000*2240*2740
43kw
48kw
R507A
Note: Standard materials: dumplings, glutinous rice balls, scallops, sea cucumbers, shrimps, scallop cubes, etc. Evaporation temperature and condensation temperature -42℃/-45℃









Equipment use: Rapid freezing of flour products, fruits and vegetables, seafood, meat products, dairy products and other prepared foods









The above parameters are for reference only. Different materials have different corresponding parameters. Please consult the technicians for details.










Why Choose Our Quick Freezing Tunnel?

Free design service.
Technical personnel go to the local installation service.
Extends Shelf Life – Locking in freshness and preventing freezer burn. Boosts Productivity – High-speed freezing for continuous processing. Complies with International Standards – Meets CQC, ISO, and CE regulations. Durable & Low Maintenance – Built for long-term reliability.
Applications
* Meat & Poultry (chicken, beef, pork)
* Seafood (fish, shrimp, scallops)
* Vegetables & Fruits (berries, peas, corn)
* Bakery & Dairy Products
* Prepared Foods (dumplings, pizza, snacks)


FAQ:


1. Who are we?

We are located in Henan, China, established in 2025, and our products are sold to North America (22%), South America (17%), Northern Europe (14%), Western Europe (12%), Middle East (10%), Eastern Europe (7%), Southeast Asia (6%), Oceania (5%), Southern Europe (2%), Africa (2%), South Asia (1%), East Asia (1%), Central America (1%). There are about 11-50 employees in our office.


2. How do we ensure quality?

Pre-production samples are always provided before mass production;

Final inspection is always carried out before shipment;


3. What can you buy from us?

Food machines such as dining carts, pizza machines, cotton candy machines, ice cream machines, popcorn machines, vending machines, etc.


4. Why should you buy from us instead of other suppliers?

We adhere to the technology research and development strategy. Technical design, material procurement, precision manufacturing and strict quality inspection are all carried out in accordance with ISO9001 standards.


5. What services can we provide?

Accepted delivery terms: FOB, CFR, CIF, EXW, FAS, FCA, DDP, Express;

Accepted payment currencies: USD, EUR, JPY, CAD, AUD, HKD, GBP, RMB, CHF;

Accepted payment methods: T/T, L/C, D/A, ABN, CREDIT, Credit card, PayPal, Cash;

Supported languages: English, Chinese, Spanish, Japanese, Portuguese, German, Arabic, French, Russian, Korean, Hindi, Italian
