Includes all taxes

1.NOTE:
Default Configuration:
· Size: 80*160mm
· Power Supply: AC220V
· Input: Universal signal input(B, S, K, E, J, T,PT100,4-20MA. etc)
· Output: Dual relay output
· Additional Output: One DC24V feed output
Customizable Options:
· Size: 160*80mm
· Power Supply: DC24V, AC90-260V
· Output: 4-20mA / RS485
Special Customization:
· Dual-loop digital display meter
· Size: 80*160mm
· Power Supply: AC220V
· Output: Four relay outputs
For customization requests, please contact us.
2.Parameters
Parameter | Specification |
Input Signal | Resistance (PT100, CU50, pressure resistors), Thermocouple (B, S, K, E, J, T, WRE), Current (0-10mA, 4-20mA, 0-20mA, input resistance ≤250Ω), Voltage (0-5V, 1-5V, input resistance ≥250Ω) |
Measuring Range | -1999 to 9999 digits |
Measurement Accuracy | 0.2%FS ±1 digit or 0.5% ±1 digit |
Resolution | 1, 0.1, 0.01, 0.001 digit |
Temperature Compensation | 0~50°C digital automatic compensation |
Display Mode | -1999 to 9999 measured value, 0-100% bar graph, -1999 to 9999 set value, triode working status indication |
Bar Graph Accuracy | ±1% |
Control Method | ON/OFF control with hysteresis |
Analog Output | DC 0-10mA (load ≤750Ω), DC 4-20mA (load ≤500Ω), DC 0-5V (load ≤250Ω), DC 1-5V (load ≤250Ω) |
Switch Output | Relay control (ON/OFF hysteresis), Contact capacity: AC220V/3A, DC24V/6A (resistive load) |
Solid-State Relay Output | SSR (solid-state relay control signal), DC 6-24V/30mA |
Communication Output | RS-232C, RS-422, RS-485, Modbus protocol |
Alarm Method | Selectable 1-4 limit alarms, LED indicator, ON/OFF relay output |
Alarm Accuracy | ±1 digit |
Protection Mode | Input circuit disconnection alarm, relay output, LED indication, over/under-range alarm, automatic reset after power loss, watchdog function |
Working Environment | -10°C to 50°C, humidity ≤85% RH (non-condensing) |
Power Supply | AC 220V ±10-15% (50Hz ±2Hz, linear power supply), AC90-260V (switching power supply), DC24V ±2V (DC power supply) |
Power Consumption | ≤5W (AC220V linear power supply), ≤4W (AC90-265V switching power supply), ≤4W (DC24V power supply) |
Weight | 420g |
Structure | Standard snap-in |
3. Features
Easy Installation– Standard snap-in design allows quick and secure mounting.
Stable Power Supply– AC 220V linear power ensures consistent performance with minimal noise.
Lightweight & Durable– Weighs only 420g, making it easy to integrate into various setups.
Comprehensive Protection– Built-in safeguards against overload, overvoltage, and short circuits.
Wide Operating Range– Functions reliably within -10°C to 50°C and 10%-90% RH humidity.
4.Applications
· Industrial automation systems
· Power supply modules for embedded devices
· Control panels and instrumentation
· Telecommunications and networking equipment








5.FAQs
Q1:Is this power supply compatible with all AC 220V systems?
A1:Yes, it is designed to work with standard AC 220V power sources.
Q2:How is the power supply installed?
A2:It features a snap-in design for quick and secure installation.
Q3: hat are the key advantages of using a linear power supply?
A3:A linear power supply provides stable voltage output with low noise, making it ideal for sensitive applications.
Would you like any modifications or additional details?
